MOORLINK M-LINKS

vryhof(product.headerbeelden)(1920x845px)(rope to rope m-link).1

Reduced installation cost and maximized installation options

The M-Link concept is a proven concept developed by MoorLink as a cost enhanced alternative to connect polyester mooring lines. With the hollow pin design (pat. pending) we have managed to integrate advantages which makes it a very competitive alternative solution for connecting polyester/composite mooring lines.

Features

  • Easier installation by eliminating the need for a large and heavy spool and allowing easier handling of the pin with a special handling tool.
  • The M-link can stand vertically and unsupported on deck.
  • Lower weight compared to links using solid shafts and spools or thimbles.
  • The risk of damaging the rope in way of the connector is minimized by designing the side plates larger then to rope OD with a margin.
  • Easy to hang off the outboard load when connecting the next segment.
  • The allowance for handling/prestretching structural capacity is ”unlimited” by utilizing a composite sling through the main hollow shaft.
Certified by ABS, DNV GL or others
Long Term Mooring (LTM)
Hollow or solid axis

Available for chain to rope, rope to rope and chain to chain connections.

Download Moorlink
product catalogue

The items in this catalogue shows the most commonly produced products and should serve as an overview of the MoorLink assortment.
